AMPLIFIER DATA
Verified RMS 13.8V Per Channel 4Ohm (Watts)@(THD), (Amps), (Version) 2X450
Verified RMS 13.8V Per Channel 2Ohm (Watts)@(THD), (Amps), (Version) 2X850
Verified RMS 13.8V Per Channel 1Ohm (Watts)@(THD), (Amps), (Version) 2X1555
Frequency Response (Hz) 20>20000
LPF (Hz) 40>20000
HPF (Hz) 15>1000
Bass Boost (Db) 0>12
Audio Signal Input Voltage (V) 220mv>6.5V
Amplifier Topology D
Recommended Wiring Kit and Accessories PWP00.1
Minimum Recommend Final Load Per Channel (Ohms) 1

KEY FACTS
Product Category Amplifiers
Version 1
Series Team
Date Added 01/12/2021
Date Modified 08/03/2022
Barcode 5060905110186
Production Status Current
Product Net Weight (g) (For Pairs/Sets Weight Is All Major Parts) 4122
Product Height (mm) 66.5
Product Length (mm) 265
Product Width (mm) 225
Complete Product Pack Weight (g) 4580
Retail Carton L (mm) 410
Retail Carton W (mm) 268
Retail Carton H (mm) 105
Operating Temperature (Degrees Celsius) 0-50
Warranty (Months) 12
Sold As Single

TECHNICAL HIGHLIGHTS
Class D Transformer Technology
High Quality RCA Connectors
Heavy Duty Screw Terminals
High Class Presentation Box (Safe Transit)
Printed Instruction Manual & Data Sheet
16V Stable RCA Inputs
Variable Subsonic Filter
Variable Low-Pass Crossover
1 Ohm Stable Operation
Variable High-Pass Crossover
Line Output For Daisy Chain Amplifier Applications

WHAT’S IN THE BOX?
1 x High Performance Amplifier
1 x BFS.2 Bassface Sticker
2 x Replacement Fuse
4 x Mounting Screws
1 x Set Instruction & Data Sheets
